Electronic/Electrical Parts and Controll Equipments
63-7710-50 Vishay B250C800G-E4/51, Bridge Rectifier, 900mA 400V, 4-Pin WOG B250C800G-E4/51
Product Description
Product Model: 63-7710-50Product Brand: Vishay Features […]
Contact Us
Product Details
Product Model: 63-7710-50
Product Brand: Vishay
Features
- Bridge Rectifiers with Wire Leads, B..C800G Series, Vishay Semiconductor. Low forward voltage drop High dielectric strength case Wire Lead structure for Printed Circuit Board (PCB) through hole mounting
Spec
- Quantity:1set(3000pieces)
- Bridge Type : Single Phase
- Peak Average Forward Current : 900mA
- Peak Reverse Repetitive Voltage : 400V
- Mounting Type : Through Hole
- Package Type : WOG
- Pin Count : 4
- Diode Technology : Silicon Junction
- Configuration : Single
- Peak Non-Repetitive Forward Surge Current : 45A
- Maximum Operating Temperature : +125 °C
- Minimum Operating Temperature : -40 °C
- Peak Forward Voltage : 1V
- Peak Reverse Current : 10µA
- Length : 9.86mm
- Dimensions : 9.86 x 8.84 x 5.6mm
- CODE No.:165-2666
