Spec

• Key Features
• Simple circuit configuration without harmonic current suppression circuit
• Small, lightweight and highly efficient
• Ability to use 105% load factor at 50 C operating ambient temperature (standard installation)
• A wide range of options (With Cover, With L Sheet Metal, Double-sided Board Coating, Volumeless)
• Key Specifications
• Output Power 153.6 W
• Input voltage range 85 ~ 132 VAC/170 ~ 264 VAC (auto-switching)/47 ~ 63 Hz
• Output voltage DC 48 V
• Output Current 3.2 A
• Efficiency (typ) 0.90/0.91 (100/200 VAC)
• Operating temperature range: -10 to + 70 degrees Celsius (-10 to + 50 C: 100%, + 60 C: 70%, + 70 C: 20%)
• Dimensions 75 x 37 x 160 mm
• Remarks No cover
• RoHS compliant
