Spec

• Key Features
• Built-in active filter circuit supports harmonic current regulation
• Higher efficiency and lower standby power
• More than 30% smaller and 20% lighter than conventional models
• Achieved 100% efficiency at 50 degrees C considering industrial applications
• Lots of options with cover, L-sheet metal, double-sided substrate coating, volumeless, remote ON/OFF control
• Key Specifications
• Output Power 103.2 W
• Input voltage range 85 ~ 265 VAC (47 ~ 63 Hz) or 120 ~ 370 VDC
• Output voltage DC 24 V
• Output Current 4.3 A
• Efficiency (typ) 0.87/0.89 (100/200 VAC)
• Operating temperature range: -10 to + 70 degrees Celsius (-10 to + 50 C: 100%, + 60 C: 75%, + 70 C: 50%)
• Dimensions 62 x 33 x 155 mm
• Remarks w/Cover
• RoHS compliant
