63-7698-12 Semtech SR05.TCT, Uni-Directional TVS Diode Array, 500W, 4-Pin SOT-143 SR05.TCT
Product Description
Product Model: 63-7698-12Product Brand: Semtech Feature […]
Contact Us
Product Details
Product Model: 63-7698-12
Product Brand: Semtech
Features
- RailClamp®, Low Capacitance TVS Diode Array, SR Series. 500 Watts Peak Pulse Power (tp : 8/20μs) ESD protection to: IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact) IEC 61000-4-4 (EFT) 40A (5/50ns) IEC 61000-4-5 (Lightning) 24A (8/20μs) Array of surge rated diodes with internal TVS Diode Protects two I/O lines Low capacitance ( ;10pF) for high-speed interfaces
Spec
- Quantity:1set(3000pieces)
- Direction Type : Uni-Directional
- Maximum Clamping Voltage : 20V
- Minimum Breakdown Voltage : 6V
- Mounting Type : Surface Mount
- Package Type : SOT-143
- Maximum Reverse Stand-off Voltage : 5V
- Pin Count : 4
- Peak Pulse Power Dissipation : 500W
- Maximum Peak Pulse Current : 25A
- ESD Protection : Yes
- Number of Elements per Chip : 1
- Minimum Operating Temperature : -55 °C
- Maximum Operating Temperature : +125 °C
- Width : 1.4mm
- CODE No.:170-0847
