63-7698-10 Semtech SMDA05.TBT, Quad-Element Uni-Directional TVS Diode, 300W, 8-Pin SOIC SMDA05.TBT
Product Description
Product Model: 63-7698-10Product Brand: Semtech Feature […]
Contact Us
Product Details
Product Model: 63-7698-10
Product Brand: Semtech
Features
- 300W Unidirectional TVS Array, SMDA Series. 300 Watts peak pulse power (tp : 8/20μs) Transient protection for data lines to: IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact) IEC 61000-4-4 (EFT) 40A (5/50ns) IEC 61000-4-5 (Lightning) 12A (8/20μs) Protects unidirectional data I/O lines
Spec
- Quantity:1set(500pieces)
- Diode Configuration : Isolated
- Maximum Clamping Voltage : 11V
- Minimum Breakdown Voltage : 6V
- Mounting Type : Surface Mount
- Package Type : SOIC
- Maximum Reverse Stand-off Voltage : 5V
- Pin Count : 8
- Peak Pulse Power Dissipation : 300W
- Maximum Peak Pulse Current : 17A
- ESD Protection : Yes
- Number of Elements per Chip : 4
- Minimum Operating Temperature : -55 °C
- Maximum Operating Temperature : +125 °C
- Width : 4mm
- CODE No.:170-0835
