Features

• 25AA512/25LC512 SPI Serial EEPROM. Microchip s 25AA512/25LC512 family of devices are 32 Kbit SPI Serial EEPROMs available in a variety of package, temperature and power supply variants. Featured are Page, Sector and Chip Erase functions typically associated with Flash based products. The Serial Peripheral Interface (SPI) is utilised to provide the required Clock Input (SCK), Data In (SI) and Data Out (SO) signals. The operation of these devices can be pa***d via a Hold pin (HOLD) which ca***s inputs to be ignored with the exception higher priority interrupts defined via the Chip Select (CS) pin. Features. 20 MHz maximum Clock Speed Byte and Page-level Write Operations (5 ms maximum): No page or sector erase required 128-byte Page Maximum Write Current: 5 mA at 5.5V, 20 MHz Read Current: 10 mA at 5.5V, 20 MHz Standby Current: 1μA at 2.5V (Deep power-down) Electronic Signature for Device ID Self-Timed Erase and Write Cycles: Page Erase (5 ms typical), Sector Erase (10 ms/sector, typical) and Bulk Erase (10 ms, typical) Sector Write Protection (16K byte/sector): Protect none, 1/4, 1/2 or all of array Built-In Write Protection: Power-on/off data protection circuitry, Write enable latch Write-protect pin Endurance: 1 Million erase/write cycles Data Retention: >200 years ESD Protection: >4000V
