Spec

• Supported protocol: TCP/IP
• Wireless LAN standards (802.11n): IEEE802.11ax, IEEE802.11ac, IEEE802.11n, IEEE802.11a, IEEE802.11 g, IEEE802.11b
• LAN port types: IEEE802.3bz (2.5GBASE-T), IEEE802.3ab (1000BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3 (10BASE-T), IEEE802.3x Flow Control, IEEE802.1Q VLAN tagging * Only LAN1 port supports IEEE802.3bz.
• Number of simultaneous wireless connection nodes: 768
• Speed: Up to 2401Mbps (IEEE802.11ax * 6 GHz), Up to 1201Mbps (IEEE802.11ax * 5 GHz), Up to 573Mbps (IEEE802.11ax * 2.4 GHz), Up to 866Mbps (IEEE802.11ac), Up to 300Mbps (IEEE802.11n), Up to 54Mbps(IEEE802.11a, IEEE802.11 g), Up to 11Mbps (IEEE802.11b)
• Security features: WPA3 Personal, WPA2/WPA3 Personal, WPA3 Enterprise, WPA2/WPA3 Enterprise 192 bit Security, WPA2 Personal (WPA2-PSK AES), WPA/WPA2 Personal (WPA/WPA2 mixed mode-PSK AES/TKIP), WPA2 Enterprise (WPA2-EAP AES)
• Accessories: Security Cover, Dedicated Key, Wall Mounting Fittings, Wall Mounting Screws, Instruction Manual
• Asbestos: Not contained
• RoHS Directive: Not compliant
• J-Moss: not supported
• Remarks of the Radio Law: Applicable to the main body
• Remarks of the Telecommunications Business Law: Beca*** it does not connect directly to public lines
• Maximum power consumption: 32 W
• Maximum power consumption (Remarks): 25.5 W for PoE
• Radio Law: Compliance
• Telecommunications Business Law: Compliance
• Date of regulatory review: 20230404
• Body size (H): 275 mm
• Body Size (W): 275 mm
• Body Size (D): 75 mm
• Body Weight: 1510 g
• Electrical Appliances and Materials Safety Act (main body): Not applicable
• Electrical Appliances and Materials Safety Act (accessories, etc.): Not applicable
• Electrical Appliances and Materials Safety Act (Note): This product is not legally covered.
