Spec

•

• Interface standard: Compliant with USB specifications Ver. 3.2 Gen1 (USB31/3.0) (Upward compatible with USB Ver. 2.0/1.1)
• 5Gbps, 480Mbps, 12Mbps, 1.5Mbps
• Connector
• One USB 3.2 Gen1 (USB31/3.0) A connector male
• USB 3.2 Gen1 (USB31/3.0) 1 male Type-C connector
• HDMI Type A (19PIN) Female x 1
• power: bus power
• < Video Output Port >
• Port Shape: HDMI Type A (19pin) Female x 1
• Supported resolutions: 3840×2160 (30 Hz), 3440×1440 (30 Hz), 2560×1440 (60 Hz), 2048×1152 (60 Hz), 1920×1200 (60 Hz), 2048×1080 (60 Hz), 1920×1080 (60 Hz), 1600×1200 (60 Hz), 1680×1050 (60 Hz), 1400×1050 (60 Hz), 1600×900 (60 Hz), 1280×1024 (60/75Hz), 1440×900 (60 Hz), 1280×960 (60 Hz), 1366×768 (60 Hz), 1280×800 (60 Hz), 1280×768 (60/75Hz), 1280×720 (60 Hz), 1024×768 (60/70/75 Hz), 800×600 (56/60/75 Hz), 640×480 (60/75Hz)
• Maximum supported resolution: 4 K/30 Hz
• Maximum number of connections: 7 for Windows, 2 for Mac
• < Common specifications >
• Current consumption (maximum): 400 mA
• Operating temperature: 0~50°C
• Operating humidity: 10~90% (non-condensing)
• Cable length: 0.1 m
• Size: W47 x D90 x H16mm
• Weight: about 76 g
• Set Contents: Main Unit, Instruction Manual
