Spec

• Color: Black
• interface standard
• USB port: Compliant with USB specification Ver. 3.2 Gen1 (USB3.1Gen1/USB3.0) (Upward compatible with USB Ver. 2.0/1.1)
• LAN ports: IEEE802.3 (10BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3ab (1000BASE-T)
• access methods: CSMA/CD
• Connector
• One male USB Type-C connector (upstream)
• USB3.2 Gen1 (USB31/3.0) A connector female x 1 (downstream)
• 1 RJ-45 (Auto MDI/MDI-X) port
• Auto-Negotiation Support
• power: bus power
• Supply voltage: 5 V
• Current consumption: 380 mA max.
• Power consumption: 2.5 W
• USB hub port current: 520 mA max. (When 900 mA is supplied from personal computer)
• Communication speed: 5Gbps/480Mbps/12Mbps/1.5Mbps (theoretical)
• PD supported: Not supported
• Destination Connector — RJ-45
• Standards: IEEE802.3 (10BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3ab (1000BASE-T)
• Transmission speed: 1000Mbps/100Mbps/10Mbps (theoretical)
• Communication mode: Full duplex/Half duplex
• Supported protocols: IPv4, IPv6
• Port shape: RJ-45 port (Auto MDI/MDI-X) with Auto-Negotiation
• Size: W62 x D38.5 x H13.5mm (excluding cable)
• Weight: 29 g (including cable)
• Cable Length: Approximately 9 cm (Excluding Connectors)
• Environmental Conditions: Operating Temperature: 0°C~40°C, Storage Temperature: -20°C~60°C Operating and Storage Humidity: Up to 0~80% (No Condensation)
• Accessory: Owner's Manual
