Spec

• Interface
• For Input/Output: HDMI Type A (19PIN) Female x 2
• For Input/Output: HDMI Type A (19PIN) Male x 1
• Switching content: HDMI Input 2/HDMI Output 1 or HDMI Input 1/HDMI Output 2
• Switching method: Body switching button
• HDMI Standard: HDMI Ver2.0b
• HDCP: HDCP1.4, HDCP2.2
• Data rate: 18Gbit/s (maximum)
• Pixel clock: 600 MHz (maximum)
• Maximum resolution: 4 K/60 Hz
• Major Supported Resolutions
• 4096×2160(60/50/30/25/24 Hz, 4:4:4/4:2:2/4:2:0) * For 4K/4096×2160(60 Hz, 4:4:4) output, only 8bit color depth is supported.
• 3840 x 2160(60/50/30/25/24 Hz, 4:4:4/4:2:2/4:2:0)
• 1920×1080p(60/50/30/24Hz)
• 1920×1080i(60/50/30/24Hz)
• 1280×720p(60/50Hz)
• 640×480p(60/50Hz)
• *It dep***s on the resolution of the TV and monitor you connect.
• HDR: support
• Supported audio formats: LPCM 2/51/7.1ch, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS
• Input DDC signal: 5 V
• device-to-device control (CEC): supporting
• *Operation is not guaranteed on all devices.
• Cable Length: Approx. 50 cm
• Power consumption (max): 0.06 W
• Operating Temperature and Humidity: Temperature/0~50°C, Humidity/80% or Less (No Condensation)
• Storage Temperature, Humidity: Temperature/-20~60°C, Humidity/80% or Less (No Condensation)
• Product size: W65 x D54.5 x H20.5mm
• Weight: about 92 g
• Set Contents: Main Unit, Instruction Manual, Warranty
