Spec

• Interface: USB HID
• Connector Shape: USB A
• Power: USB power supply
• PCS: 30%
• read depth
• Code39(4mil)/0mm~150mm
• EAN-13(13mile)/35mm~200mm
• QR Code(7mile)/20mm~85mm
• Data Matrix(7mil)/20mm~115mm
• Light Source: Direct/White LED, Diff***/Red/Blue LED
• Scan speed: 70 frames/second
• Readable codes (1-D): JAN, EAN, UPC-A, UPC-E, NW-7 (Codabar), Interleaved 2 of 5 (ITF), Code 39, Code 128, ISSN, MSI, Code 93, GS1-128
• *Some bar codes cannot be read dep***ing on the size or number of digits.
• Readable code (2D): QR Code, Micro QR, Data Matrix
• *Some bar codes cannot be read dep***ing on the size or number of digits.
• Japanese QR code: Supported
• Reading Method: CMOS
• Resolution 2 dimensional code: 0.127 mm
• Resolution 1 dimensional code: 0.0762 mm
• Reading Angle: Pitch/55°, Skew/55°, Tilt/360°
• Environmental conditions: Operating temperature 0~50°C, humidity 5~95% (non-condensing), Storage temperature 40~70°C, humidity 5~95% (non-condensing)
• Current consumption (operating): 100 mA Max. 430 mA
• Protection Class: IP65
• Shock Resistance: Approx. 2 m
• Size: W181 x D136 x H77mm
• Weight: about 356 g
• Set Contents: Main Unit, Owner's Manual, Warranty
