63-7686-08 HARWIN M22-30 Female Connector Housing, 2mm Pitch, 10 Way, 1 Row M22-3011000
Product Description
Product Model: 63-7686-08Product Brand: HARWIN Features […]
Contact Us
Product Details
Product Model: 63-7686-08
Product Brand: HARWIN
Features
- Socket Housings. Single and double row crimp socket shells which mate with 2mm pitch headers. M22-301 Series SIL housings mate with M22-201/203 Series headers typical stock nos. ; 681-3287 681-3287 and ; 681-3316 681-3316 respectively M22-302 Series DIL housings mate with M22-202/204 Series headers typical stock nos. ; 681-3297 681-3297 and ; 681-3326 681-3326 respectively Shells accept crimp terminals stock nos. ; 547-3245 547-3245 (tin plate) or ; 547-3289 547-3289 (gold plate)
Spec
- Quantity:1bag(10pieces)
- Number of Contacts : 10
- Number of Rows : 1
- Pitch : 2mm
- G***er : Female
- Mounting Type : Cable Mount
- Series : M22-30
- For Use With : M22 Series Connector
- Body Orientation : Straight
- Length : 20mm
- Width : 2mm
- Depth : 7.1mm
- Housing Material : Nylon
- CODE No.:681-3344
