Spec

• Network Standard:
• Wireless: IEEE802.11 a/b/g/n/ac/ax
• Ethernet: IEEE802.3/u/ab/bz
• Radio Frequency: 2.4 GHz, 5 GHz (When using the 5 GHz band, *** of 5.2 GHz and 5.3 GHz band radio waves outdoors is prohibited by the Radio Law. In addition, when using radio waves in the 5.3 GHz and 5.6 GHz bands, communication may be temporarily interrupted by the DFS function to avoid interference from weather radars, etc. )
• Transmission Rate (MAX):
• 2.4GHz: 574Mbps at 11ax
• 5GHz: 1,200Mbps at 11ax
• Ethernet: 2.5Gbps
• Number of PoE ports: 1
• Standard Antenna:
• 2 2.4 GHz 5dBi omni-directional antennas
• Two 5-GHz 5-dBi omni-directional antennas
• Power Supply: PoE Power Supply (IEEE802.3 at)
• Dedicated PoE Adapter:
• Input: 100~240 VAC
• Output: 54 V (Do not *** the supplied PoE adapter with anything other than the DAP-P3 W 6.). The PoE adapter supports up to 240 VAC, but the attached AC cord is up to 125 VAC. )
• Power consumption: 15.9 W
• utility software: configuration utility (accessed from a web browser)
• Operating temperature range: -20~60°C
• Protective Structure: IP67
• Mounting Method: Pole Mounting, Wall Mounting
• External Dimensions (mm): W124.0 x D47.0 x H190.0 (Excluding Antenna and Protrusion)
