63-7672-27 Recom RB 1W Isolated DC-DC Converter Through Hole, Voltage in 10.8 → 13.2 V dc, Voltage out 9V dc RB-1209S
Product Description
Product Model: 63-7672-27Product Brand: Recom Features […]
Contact Us
Product Details
Product Model: 63-7672-27
Product Brand: Recom
Features
- Operating temperature is without derating. Recom 1W SIP Single/Dual Output Unregulated Isolated DC-DC Converter - RE/RB Series. Single ; dual output options 1kVdc isolation UL94V-0 package material SIP7 package with industry standard pin-outs
Spec
- Quantity:1piece
- Output Voltage : 9V dc
- Input Voltage Range : 10.8 → 13.2 V dc
- Input Voltage Nominal : 12 V dc
- Isolation Voltage : 500V ac
- Power Rating : 1W
- Output Current : 111mA
- Mounting Type : Through Hole
- Number of Outputs : 1
- Package : SIP
- Minimum Temperature : -40°C
- Maximum Temperature : +85°C
- Depth : 10.2mm
- CODE No.:672-7372
