Electronic/Electrical Parts and Controll Equipments
63-7671-86 Recom Switching Regulator, 32V dc Input, 12V dc Output, 1A R-78B12-1.0L
Product Description
Product Model: 63-7671-86Product Brand: Recom Features […]
Contact Us
Product Details
Product Model: 63-7671-86
Product Brand: Recom
Features
- EN-55022, EN-55024, EN-60601-1-2, EN-60950-1. De-rate above 71°C operating temperature. MTBF to MIL-HDBK 217F. R-78Bxx 1.0L Series. Non isolated Medical safety approval EN-60601-1-2 No need for heat sinks High efficiency Wide input voltage range, up to 34V Thermal shutdown and continuous short circuit protection Low ripple and noise Low profile Pin-out compatible with LM78XX Linear regulators L version with 90° pins
Spec
- Quantity:1set(42pieces)
- Input Voltage : 32V dc
- Output Voltage : 12V dc
- Number of Outputs : 1
- Output Current : 1A
- Mounting Type : Through Hole
- Package : SIP
- Minimum Temperature : -40°C
- Maximum Temperature : +85°C
- Efficiency : 96%
- MTBF : 6584000h
- Load Regulation : 0.25%
- Line Regulation : 0.1%
- Ripple And Noise : 25mV Pk-Pk
- Width : 17.5mm
- CODE No.:166-8997
