63-7669-39 Mean Well 59W Dual Output Embedded Switch Mode Power Supply SMPS, 1.4 A, 750 mA, 27.6V dc Open Frame PSC-60B
Product Description
Product Model: 63-7669-39Product Brand: Mean Well Featu […]
Contact Us
Product Details
Product Model: 63-7669-39
Product Brand: Mean Well
Features
- UL60950-1, TUV EN60950-1. cULus, TUV, CB. MTBF to MIL-HDBK-217F @ 25°C. Main output voltage is adjustable (PSC-60A 12-15V, PSC-60B 24-29V). 2. PSC-60 Series - Battery Backed PSUs. Universal AC input / Full range Short circuit, overload ; over voltage protection Battery charger UPS function Battery low protection / battery polarity protection by f*** Alarm signal for AC OK and Battery low 100% full load burn-in test Cooling by free air convection For suitable mating connectors for the PSC-60 series see stock no ; 381-845 381-845
Spec
- Quantity:1piece
- Output Voltage : 27.6V dc
- Output Current : 1.4 A, 750 mA
- Power Rating : 59W
- Number of Outputs : 2
- Input Voltage : 127 → 370 V dc, 90 → 264 V ac
- Mounting Type : Chassis Mount
- Package Type : Open Frame
- Length : 101.6mm
- Width : 50.8mm
- Depth : 29mm
- Weight : 130g
- Maximum Temperature : +70°C
- Minimum Temperature : -20°C
- CODE No.:670-1204
