Spec

• Compatible Models
• Compatible models: Windows PC with USB 2.0 port Type-C/Standard A connector, Apple Mac series, Chromebook, Android STB compatible models
• Remarks * Only the DS-ASTB1 series Android terminal is supported OSWindows 11
• Windows 10 IoT Enterprise
• Windows 10Windows 8.1
• macOS 10.12~13
• Chrome OS
• Specifications
• Camera: 5 million pixel CMOS sensor
• Maximum resolution: 1920 x 1080
• Shooting range: 30 cm - ∞
• F value: F2.0
• Maximum frame rate: 30fps
• Supported formats: MJPEG, YUV
• Angle of view (maximum)
• 180° Split Mode (180° x 2) Horizontal 180° Vertical approx. 52°
• 360° Panorama +1 Screen Mode Horizontal 360° Vertical 53° (Panorama Image) Horizontal 124° Vertical 53° (1 Screen)
• 360° Panorama +2 screens Horizontal 360° Vertical 53° (Panorama image) Horizontal 59° Vertical 53° (2 screens)
• 3 Screen modes: horizontal approx. 59°, vertical approx. 53° (main screen) horizontal approx. 71°, vertical approx. 51° (sub screen)
• 360° Panorama mode Horizontal 360° Vertical approx. 54°
• Front Mode Horizontal Approx. 180° Vertical Approx. 89°
• Digital zoom: 3 × (360° Panorama mode), 2 × (Front mode)
• focus: fixed
• Speaker: 1 full range
• Microphone: Two omni-directional microphones
• Sound Collection Range: Recomm***ed/Approx. 1.5 m, Maximum/Approx. 3 m
• Audio Processing: Echo Canceller, Noise Reduction, Auto Gain Control
• Applications verified to work
• Microsoft Teams
• Skype
• Zoom
• Google MeetGoogle Hangouts
• Cisco Webex Meetings※
• *For 360° Panorama mode, select
• Set "Adjust camera brightness" to OFF or Manual.
• Tripod support: Yes (1/4 inch)
• interface: USB 2.0
• Connector shape: USB Type-C connector, USB Standard A connector
• Supply voltage rating (DC): USB bus power
• Operating temperature range: 0~40°C
• Operating humidity range: 20~85% (non-condensation)
• External Dimensions Approx.
• 112 (W) x 112 (D) x 206 (H) mm * USB cable not included
• Cable Length: Approx. 2 m
• Weight (body only): Approx. 560 g
• Weight (packed): Approx. 780 g
• Approved standards: RoHS Directive compliance (10 substances), VCCI Class B warranty period 1 year
• Attached items: lens cover, cleaning cloth, instruction manual
