Spec

• Output Power: 600 W
• Input voltage range: AC 85 ~ 265 (47 ~ 63 Hz) or DC 120 ~ 330
• Output Voltage: 24 VDC
• Output Current: 25 A
• Efficiency (typ): 84%/88% (100 VAC/200 VAC)
• Operating temperature range:? 20 to + 70 (? 20 to + 50 C: 100%, + 70 C: 20%)
• Dimensions: 61 x 120 x 190 (mm)
• Remarks:
• Simple function model that maintains basic performance and optimizes additional functions
• Long service life: Electrolytic capacitors with a service life of 5 years or more (electrical contact with a service life of 5 years or more at Ta 40 degrees C load factor of 100% 24 hours/day)
• Set covered model with standard
• Set optional DIN rail mounting type and fittings (Lineup of products with DIN rail fittings for 50 W, 100 W and 150 W 24 V output types)
• UL 508 compliant (5 V, 12 V and 24 V output types for 150 W and below, 24 V output type for 300 W and 24 V output type for 600 W are expected to be acquired.)
• It can withstand an input surge of 300 VAC for 5 seconds.
• RoHS compliant
