Features

• Mounting bezel / accessories, operating instructions and connector. Dimensions stated include bezel, module dimensions only are 39 x 71.5 x 11.3mm (excluding pins at 8.4mm). 19mm 3.5 Digit Meter with Bicolour Alarm Backlight, Lascar DPM 950S-FPSI. A standard 3.5 digit voltmeter that can be ***d as a dual colour stop/go display. During standard operation the display is green, however if the reading goes outside a programmable threshold the display will turn red. 200mV FSD Linearity ±1 count Auto-zero, auto-polarity Dual colour backlight with programmable high and low levels (backlight current is 35mA at 5V Nom.) Open collector outputs that mirror the backlight status 6 way DIP switch and 2 push button set up 16 way IDC cable header Panel cut-out 40 x 72 mm
