65-9010-25 Mini Cock Inner Diameter Φ5 mm 25 g Plug Backflow Prevention Type C335PHBSTEELNBR
Product Description
Product Model: 65-9010-25Product Brand: NITTO KOHKI CO. […]
Contact Us
Product Details
Product Model: 65-9010-25
Product Brand: NITTO KOHKI CO., LTD.
Features
- For low pressure.
- Compact, lightweight and one-touch connection with emphasis on workability.
- Piping connection for fusing work can be made from the container to the blowpipe.
- The body is chrome plated and has excellent corrosion resistance. In addition, the plug is heat-treated to improve durability.
- In order to prevent misconnection, the fitting size is changed for oxygen and fuel gas, and the sleeve for fuel gas is colored with copper plating to ensure safety.
- Standardized mounting shapes for a wide range of fusing applications.
Spec
- Opposing Hose Size: Inner Diameter Φ5mm
- Mass (g): 25
- L(mm):56.5
- C(mm):21.1
- A(mm):21
- ΦH(mm):15
- ΦJ(mm):6.2
- ΦB(mm):3.1
- Valve Structure: One Way Opening/Closing Type
- Applicable fluids: oxygen, fuel gas
- Body Material: Steel (Chrome Plated)
- Maximum Working Pressure (MPa{kgf/cm2}): 0.7{7}
- Pressure Capacity (MPa{kgf/cm2}): 1.0{10}
- Seal Material: Nitrile Rubber
- display symbols: NBR
- Operating Temperature Range (°C): -20 to +80
- Remarks: Standard Material
- Mounting Shape: Hose Nipple
- Type: Plug
- Specifications: Backflow Prevention Type
