Spec

• Compatible device: PC with VGA terminal and USB-A or PS/2 port
• Operating System (Windows): 11/10/8.1/8/7/Vista/XP
• macOS: Mac OS X Cheetah 10.1 to macOS Monterey 12
• Supported mo***: Wired mo*** (USB-A terminal, PS/2 terminal) Wireless mo*** (USB receiver 2.4 GHz)
• *The software may not operate correctly if the mo*** emulation function is turned on. In this case, turn off the mo*** emulation function.
• Supported keyboards: Wired keyboard (USB-A terminal, PS/2 terminal), Wireless keyboard (USB receiver type 2.4 GHz) * For Mac terminals, *** a keyboard with a [ScrollLock] key.
• Supported displays: VGA terminal
• Interface (PC side): SPHD connector (female) * Only the included cable can be ***d since this is a proprietary standard.
• Interface (console side)
• Mo***: Mini-DIN 6-pin (PS/2) female x 1, USB-A female x 1
• Keyboard: Mini-DIN 6-pin (PS/2) female x 1, USB-A female x 1
• Display: D-Sub 15 pin (VGA) female x 1
• Maximum resolution: 2048 x 1536 @60 Hz * VESA DDC2B compliant
• Maximum number of PC connections: 2
• Switching method: Select switch, hot key ([ScrollLock] x 2 times + [Enter] key), mo*** scroll button * Operation by mo*** scroll requires setting by the hot key.
• Switching sound: Yes/No * Switching is possible with hot key.
• Power: USB bus power (supplied from the selected PC)
• Accessory: KVM Cable (SPHD-VGA, USB, PS/2) Approx. 1.0 m x 2 pcs
• Size: width 130 x depth 75 x height 44 mm
• Weight: 460 g * Cable not included
• Warranty period: 1 year
• VCCI Class B: supported
