63-7662-07 Recom RP10 EW 10W Isolated DC-DC Converter Through Hole, Voltage in 9 → 36 V dc, Voltage out ±15V dc RP10-2415DEW
Product Description
Product Model: 63-7662-07Product Brand: Recom Features […]
Contact Us
Product Details
Product Model: 63-7662-07
Product Brand: Recom
Features
- UL 609501. UL recognised. Operating temperature range is with derating. MTBF to BELLCORE TR-NWT-000332. Recom 10W Single/Dual Output Regulated Isolated DC-DC Converter - RP10-EW Series. 10W 2x1" Metal Case 4:1 wide input range Regulated outputs 1.6kV input/output isolation Six side continuous shield Efficiency up to 84% Fixed operating frequency
Spec
- Quantity:1set(9pieces)
- Output Voltage : ±15V dc
- Input Voltage Range : 9 → 36 V dc
- Input Voltage Nominal : 24 V dc
- Isolation Voltage : 1.6kV dc
- Power Rating : 10W
- Output Current : ±333mA
- Mounting Type : Through Hole
- Number of Outputs : 2
- Minimum Temperature : -20°C
- Maximum Temperature : +85°C
- Series : RP10 EW
- CODE No.:166-9067
