Spec

• Supported devices: Android smartphones, tablets, and Windows PCs that support Miracast * The connection procedure varies dep***ing on the device. For details, refer to the owner's manual of the terminal.
• Supported OS: Android 12/11/10, Windows 11/10 * Not supported on iOS, iPadOS, and MacOS.
• Wireless LAN: IEEE802.11b/g/n Frequency: 2.4 GHz, Number of Channels: 1~13ch (Auto), Access Method: Wi-Fi Direct, Access Point
• Wireless LAN Range: Approx. 10 m (with no obstructions) * Dep***ing on the terminal ***d and radio wave environmental conditions, video and/or audio may be interrupted.
• Also, communication over the wall is not available.
• Maximum resolution: FullHD (1920×1080) * Some TVs and monitors may not be able to output images at the correct screen size.
• Video/audio formats: MPEG-2/H. 264/VC-1/AVS/MPEG4 * Dep***s on codec supported by Miracast compatible terminal.
• *Frame dropping may occur dep***ing on the live environment.
• Input interface: Wi-Fi, USB Type-CTM power supply
• Output Interface: HDMI Type-A
• Operating Temperature Range: Temperature: 5~35°C
• Operating humidity range: Humidity: 20~80% (non-condensation)
• Dimensions (Width x Depth x Height): Approx. 65.1 x Approx. 65.1 x Approx. 15.0 mm
• Weight: about 43 g (body only)
• Enclosure Material (Color): Black
• Power supply: DC5V * Power can be supplied from a TV equipped with a USB-A port (If your TV has more than one USB port, select the recording USB port.). Purchase a USB-AC adaptor if necessary (PD compatible charger cannot be ***d).
• Warranty period: 1 year
• Legal compliance: TELEC/JATE
• Accessories: HDMI cable, USB Type-CTM to USB-A cable (for power supply), Owner's Manual
