63-7658-33 TRACOPOWER TMV 1W Isolated DC-DC Converter Through Hole, Voltage in 21.6 → 26.4 V dc, Voltage out 15V dc TMV 2415S
Product Description
Product Model: 63-7658-33Product Brand: TRACOPOWER Feat […]
Contact Us
Product Details
Product Model: 63-7658-33
Product Brand: TRACOPOWER
Features
- 3. Traco 1W SIP Single/Dual Output Unregulated Isolated DC-DC Converter - TMV Series. The Traco Power TMV series is a range of miniature isolated, 1 Watt, DC/DC converters in a SIP package. The SMD technology of these isolated converters makes it possible to offer a product with high performance at low cost. The TMV DC-DC converters require only 1.2 cm ;sup>2 ;/sup> board space and are the perfect solution for space critical applications for board level power distribution. Single-in-line (SIP) package Isolated single and dual output models I/O isolation 3000Vdc High efficiency up to 81% Operating temperature range –40°C to +85°C Pin-compatible with other manufacturers 100% Burn-in (8 h) Lead free design, RoHS compliant
Spec
- Quantity:1piece
- Output Voltage : 15V dc
- Input Voltage Range : 21.6 → 26.4 V dc
- Input Voltage Nominal : 24 V dc
- Isolation Voltage : 3000V dc
- Power Rating : 1W
- Output Current : 65mA
- Mounting Type : Through Hole
- Number of Outputs : 1
- Efficiency : 79%
- Package : SIP 7
- Minimum Temperature : -40°C
- Maximum Temperature : +85°C
- Depth : 10.2mm
- CODE No.:666-4045
