Spec

• < Confirmed Game Machine >
• Game machine (capture method)
• PlayStation®5(HDMI)※1
• PlayStation®4 Pro (HDMI) * 2, 3
• PlayStation®4(HDMI)※3
• PlayStation®3 (Analog) * 4
• PlayStation®2 (Analog)
• PlayStation® (analog)
• PlayStation®VR(HDMI)※5
• PlayStation®Classic(HDMI)
• Nint***o SwitchTM(HDMI)
• Wii UTM(HDMI)
• Xbox One S®(HDMI)※2
• Xbox One®(HDMI)
• Nint***o Classic Mini ComputerTM (HDMI) * 6
• Nint***o Classic Mini Super FamiconTM (HDMI) * 6
• Sega Saturn ® (Analog)
• Super Famicom ® (analog)
• Family Computer ® (Analog)
• Retrofreak (HDMI) # 6
• *1 Make sure to uncheck [Settings] → [System] → [HDMI] → [Enable HDCP].
• *2 4K resolution cannot be displayed or recorded.
• *3 Select [Settings] → [System] → [Enable HDCP].
• *4 Recording via HDMI cable is not supported. Make an analog connection using the supplied AV cable, and select [Composite/S terminal] from (Settings) → [Display Settings] → [Video Output Settings]. You also need to select [Audio input terminal/SCART/AV MULTI] from [Set audio output].
• *5 Use the processor unit included with the PSVR.
• *6 Since the game video output is 720p, it cannot be recorded in full HD.
• *This product has been indep***ently verified by our company. Please refrain from making inquiries to each manufacturer.
• < Specifications >
• Interface
• HDMI connector: Input x 1, Output x 1 (pass-through/CEC supported)
• Headset connector: 3.5 mm 4 pole mini jack x 1 (CTIA standard standard)
• AV input jack: 3.5 mm 4-pole mini jack x 1 * For connection to the supplied AV input conversion cable
• SD card slot: 1 for recording and playback
• USB port: 1 USB 2.0 Standard A
• Supported Media (Sold Separately)
• Supported cards: SD card, SDHC card, SDXC card
• Speed: Class 2~10, UHS-I Speed Class 1~3
• *Full HD must be Class 6 or higher to record in the highest and highest quality.
• Maximum capacity: 128GB
• Supported USB Storage: USB hard disk, USB memory
• *If NTFS formatted storage is attached, a format is required. If you have saved any important data, back it up beforehand.
• *FAT32 format/exFAT is supported.
• *Storage larger than 2TB is considered 2TB.
• *If more than 2TB of storage is attached, it will be formatted. If you have saved any important data, back it up beforehand.
• *It does not support password locking or encrypted storage.
• External Dimensions: Approx. 14 (W) x 32 (D) x 60 (H) mm (Excluding Protrusion)
• Weight: about 160 g(Button Battery Included, AC Adapter Excluded)
• Weight (when packed): Approx. 470 g
• Power: 100 VAC 50/60Hz (AC Adapter)
• Power consumption: 3.8 W (Typ)
• Operating temperature range: 5~35°C
• Operating humidity range: 20~80% (non-condensation)
• Certification: VCCI Class B, Electrical Appliances and Materials Safety Act (AC adapter)
• Warranty period: 1 year
• Caution
• You cannot record copyright protected images such as DVDs and digital broadcasts.
• Do not *** the images and sounds recorded with this product for any purpose other than personal viewing.
• It does not support 4K resolution display, recording, or playback.
• < Recording Specifications >
• Movie recording (16:9)
• Image
• Recording format: MPEG-4 AVC/H. 264 (MP4)
• Image sizes: 1920 x 1080, 1280 x 720, 720 x 480
• Frame rate: 60fps30fps, 60fps, 60fps
• Bit rates: 36/28Mbps, 16Mbps, 12Mbps, 4Mbps
• Voice
• recording methods: AAC
• Sampling rate: 48 kHz
• Bitrate: 256kbps
• < Supported Resolution >
• Input: 1920 x 1080 (60p/60i/30p), 1280 x 720 (60p), 720 x 480 (60p)
• Output: 1920 x 1080 (60p/60i/30p *), 1280 x 720 (60p), 720 x 480 (60p)
• *Pass-through mode only
• < Supported formats >
• Movies: Only MP4 movies recorded with this product are supported.
• Photos: JPEG/photos edited on a computer cannot be played back.
• *Not all files can be played in supported formats.
• < Approximate Recording Time >
• Recording quality: 64GB, 128GB, 1TB, 2TB
• Full HD (Best Quality): Approx. 3.5 hours, 7 hours, 55 hours, 110 hours
• Full HD (High Quality): Approx. 4.5 hours, 9 hours, 75 hours, 150 hours
• Full HD (standard definition): Approx. 8 hours, 16 hours, 125 hours, 250 hours
• HD: Approx. 10 hours, 20 hours, 160 hours, 320 hours
• SD Quality: Approximately 30 hours, 60 hours, 480 hours, 960 hours * The maximum recording time per file is 10 hours.
• < Attachments >
• Attached Items: HDMI cable, AC adaptor, AV input conversion cable (Composite video input: RCA pin x 1, External line input: RCA pin (L/R) x 1 each), Owner's Manual, Button battery for the built-in clock (Model No. CR2025) x 1 * Installed on the instrument
