Electronic/Electrical Parts and Controll Equipments
63-7648-90 Vishay GBPC3508-E4/51, Bridge Rectifier, 35A 800V, 4-Pin GBPC GBPC3508-E4/51
Product Description
Product Model: 63-7648-90Product Brand: Vishay Features […]
Contact Us
Product Details
Product Model: 63-7648-90
Product Brand: Vishay
Features
- UL E54214. Bridge Rectifiers with Push-on Terminals, GBPC35 Series, Vishay Semiconductor. High Current 35 Amperes Universal, 3-way terminals: Push-on, wrap around or solder Glass passivated chip junction Low thermal resistance
Spec
- Quantity:1piece
- Bridge Type : Single Phase
- Peak Average Forward Current : 35A
- Peak Reverse Repetitive Voltage : 800V
- Mounting Type : Screw Mount
- Package Type : GBPC
- Pin Count : 4
- Configuration : Single
- Peak Non-Repetitive Forward Surge Current : 400A
- Maximum Operating Temperature : +150 °C
- Minimum Operating Temperature : -55 °C
- Peak Forward Voltage : 1.1V
- Peak Reverse Current : 5µA
- Length : 28.8mm
- Width : 28.8mm
- CODE No.:629-6336
Related product recommendations
You may also be interested in the following products
Electronic/Electrical Parts and Controll Equipments
63-6762-59 1458mm Synthetic Rubber Hydraulic Hose Assembly, 330bar Max Pressure 110-2007
model: 63-6762-59
brand: RS PRO
Electronic/Electrical Parts and Controll Equipments
63-7722-68 RS PRO 4700μF 35V dc Aluminium Electrolytic Capacitor, Through Hole 22 (Dia.) x 35mm +105°C 22mm 10mm 35mm 706-3446
