Spec

• Size and Weight
• Single Head Shaping Size (Width x Depth x Height): 330 x 240 x 240 mm
• Dual Head Shaping Size (Width x Depth x Height): 295 x 240 x 240 mm
• Body Weight: 30 kg
• Body Size (W x D x H): 607 x 596 x 465 mm
• Power
• Input: General 100-240 V, 50/60Hz
• Output: 350 W, 24 V
• Printer
• Output Method: FFF (Heat Dissolved Filament Production) Method
• Print Head: Indep***ent Dual Extruder (IDEX)
• Filament: 1.75 mm diameter
• Positioning accuracy: X axis/0.78125, Y axis/0.78125, Z axis/0.078125micron
• Output speed: 30-150 mm/s
• Maximum platform temperature: 110 deg.
• Platform Material: Silicon Material
• Platform Horizontal Adjustment: Auto Calibration
• Lamination Pitch: 0.02-0.65 mm (0.02 -0.3 mm is recomm***ed for 0.4 mm nozzles)
• Nozzle Diameter: 0.2/0.4/0.5/0.6/0.8 mm
• Maximum nozzle temperature: 300 °C
• Operating noise: 50dB or less
• Connection method: Wi-Fi, LAN, USB, Ethernet
• Recomm***ed operating environment: 15-30°C, 10 ~ 90% relative humidity
• Certification: CB, CE, FCC, RoHS, RCM
• Software
• slicing software: ideaMaker
• Input File Formats: STL, OBJ
• Operating system: WindowsXP or later, Mac OS10.7 or later, Ubuntu14.04 or later
• Output File Format: Gcode
• Controls
• User Interface: 7-inch Touch Screen
• Resolution: 1024 x 600
• Motion Controller: Atmel ARM Cortex-M4 120 MHz FPU
• Control Chip: NXP ARM Cortex-A9 Quad 1GHz
• Memory: 1GB
• Flash memory: 8GB
• Ports: 2 USB 2.0/1 Ethernet
