Spec

• Ethernet standards: IEEE802.3ab (1000BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3i (10BASE-T)
• *Supports "Auto MDI/MDI-X" and "Auto-Negotiation" on all ports Communication system CSMA/CD, full duplex/half duplex
• transmission code
• 1000BASE-T:8B1Q4+5PAM
• 100BASE-TX:4B/5B+MLT-3
• 10BASE-T: Manchester code
• Switch function: Yes (all ports)
• switching methods: store and forward
• Flow Control: IEEE802.3x (Full-duplex)/Back Pressure (Half-duplex)
• MAC address table — 8,192 entries (aging time 300 seconds)
• Maximum packet transfer rate
• 1000BASE-T:1,488,095pps
• 100BASE-TX:148,810pps
• 10BASE-T:14,881pps
• Buffer capacity: 512Kbytes
• Jumbo frames: maximum size 9,216bytes
• VLANs: port VLAN, tagged VLAN (tag number: 1~4094), multiple VLAN (number of groupings: 4094)
• IEEE802.1X authentication — IEEE802.1X Proxy Authentication feature (EAP-MD5/EAP-TLS/PEAP (MS-CHAP v2/GTC)/EAP-TTLS (PAP/CHAP/MS-CHAP/MS-CHAP v2)); IEEE802.1X MAC address-based authentication feature (EAP-MD5)
• Our response completed
• RADIUS server: RADIUS package
• Display LED:
• Power: Link/Act
• Loop detection/notification
• Other Features: ACL (Access Control List), Spanning Tree, Port Mirroring, SNMP Support (v1/v2c/v3), IEEE802.3ad Link Aggregation, LLDP, QoS, IGMP Snooping (v2/v3), MLD Snooping (v1/v2), Storm Control (Storm Control), EAPOL (IEEE802.1X) Frame Transparency, BPDU Frame Transparency, Loop Detection/Prevention, Power Saving (Support for IEEE802.3az Energy Efficient Ethernet (EEE), automatic cable length detection, link down detection, and link speed detection), Log Management (S*** to Syslog Server), Web Configuration Screen (Japanese), Automatic Firmware Update, Configuration Save/Restore, Magical Finder Support
• Required Software: Internet Explorer 10~11, Chrome, Microsoft Edge, Safari8~9, Magical Finder
• Fan: None
