Spec

• Ultra-compact, high power density, height 2 U bench-top type (* Rack mountable in 19 inch dedicated case) Ideal simulation for evaluating systems and equipment that *** solar cells as source Equipped with function generator for evaluating electronic devices Low ripple noise Worldwide compatible safety design USB, RS -232, RS -485 interfaces Standard (* LAN, GPIB, insulated analog board mountable (optional) External analog controllable Master/Slave parallel operation capable (up to 6 units) Equipped with last setting memory function
• (The settings are stored in memory, and even if the power is turned off, the settings are stored) Equipped with Auto Start and Safe Start
• Input voltage range: 85 ~ 265 VAC (47 ~ 63 Hz)
• Forced air cooling with built-in cooling fan
• Operating ambient temperature: 0 ~ 50 degrees Celsius
• Compliance with safety standards UL 61010 -1, EN 61010 -1, IEC 61010 -1 each certification UL 60950 -1, EN 60950 -1
• Size (mm)
• (W x H x D)83 x 70 x 350
• (Same size for both 200/400/600/800 W4 types)
• External control ON/OFF controllable
• Output GOOD signal 4 -5 V: OK, 0 V: NG, 500 ohm series resistance
• Output Voltage Programmable Voltage Control/Resistance Control
• Output current programmable voltage control/resistance control
• Remotely Sensable
• *Note: The unit does not come with a power cable. Z-J (Japanese specification) sold separately is required.
• RoHS compliant
