Spec

• Mounting: Printed circuit boards
• Number of contact poles: 3
• Coil Rating/DC Voltage: AC 100/(110) V
• Coil rating/current: 11.7/12.9 mA
• Rated/coil operating voltage: 80% or less
• Rated/coil return voltage: 30% or more
• Contact Rating/Resistance Load DC: 24 V5 A DC
• Contact Rating/Resistance Load AC: 220 V5 A AC
• Contact mechanism: Single
• Protection structure:
• Size: 28 mm x 21.5 mm x 36 mm
• Operating temperature range - (deg. C): -55 to + 70 deg. C
• Remarks:
