Features

• UL; CSA; ENEC. See stock number ; 133-6287 133-6287 for a suitable splashproof PVC cover. The current rating and life expectancy figures quoted are nominal, please see datasheet for further ratings. Marquardt 1858 Series Rocker Switches. Marquardt 1858 series of miniature double pole single throw rocker switches. The non illuminated 1858 rocker switches are suitable for *** in Class II appliances and are available in a choice of PCB mount or 4.8mm Faston/Quick Connect style tab terminals with or without abrasion-proof on-off leg***s. The miniature rocker switch material is immediately self-extinguishing to UL94V-0 and has a silk matt surface finish that snap fits into panel cut-outs with a panel thickness of between 0.75 and 3mm, the fixing ribs on the switch housing ensures a tight fit. These rocker switches have silver contacts with a DPST (on-off) switching format, a contact resistance ;100mΩ and an insulation resistance of >100MΩ. A transparent PVC cover is available to protect the 1858 series of rocker switches from dust and water ingression and to give the rocker switch actuator an IP64 rating. High inrush current (capacitive) up to 100A Contact distance ≥3mm Operating force ≤5N UL 94 V-0 flammability rated Conforms to the ho***hold appliances standard IEC/EN 60335-1:2001/2002 chapter 30
