Spec

• Output Power: 82.5 W
• Input voltage range: AC 85 ~ 265 (However, 90% load derating below 90 VAC)
• Output Voltage: 3.3 VDC
• Output Current: 25 A
• Efficiency (typ): 79%/81% (100 VAC/200 VAC)
• Operating temperature range:? 10 to + 71
• Dimensions: 25 x 82 x 160 (mm)
• Remarks:
• Wide input, ultra-thin (1U, 2U rack sizes)
• Harmonic Current Regulation EN 61000 -3 -2 Compliant
• Certified safety standards (UL, C-UL, T? V), Electrical Appliances and Material Safety Law compliant, CE mark compliant
• EMS Standard EN 61000 -4 -2, 3, 4, 5, 6, 8, 11 Compliance
• Radiation, conducted noise FCC-B, VCCI-B compliant
• Built-in remote ON/OFF function (internal switch switching)
• Electrolytic capacitor life of 60,000 hours or more
• RoHS compliant
