Spec

• Size (mm): 610 x 550 x 505
• Internal Capacity (L): Approx. 30
• Weight (kg): Approx. 38
• Temperature Control Range: Room Temperature +10~300°C
• Temperature Control System: PID Control/SSR Output
• Logger function: Always records when the power is turned on.
• Recording interval: 1 to 255 minutes (optional setting)
• Can be output to USB flash drive.
• Additional function: Program function (maximum 8 steps/8 patterns)
• Safety features: liquid expansion type excessive temperature rise prevention device, door switch, earth leakage breaker, burnout function
• Heater Capacity: 800 W
• Temperature Sensor: Resistance Temperature Measuring Body (Pt100 Ω)
• Exterior/Interior: Steel Coating/SUS304
• Measurement Hole: φ5 mm (1 Location)
• Shelf Pitch/Number of Racks: 30 mm/7 Racks
• Load Capacity of Shelf Plate: 15 kg/Sheet
• Rated current: 8 A
• Power: 100 VAC 50/60Hz
• Cord Length: 1.8 m (3P Plug)
• Accessories: Shelf Boards x 2, Shelf Board Rails x 2 Sets, Vent Cover
