Electronic/Electrical Parts and Controll Equipments
63-7580-30 T405-600T 4A, 600V, TRIAC, Gate Trigger 1.3V 5mA, 3-pin, Through Hole, TO-220AB STMicroelectronics T405-600T
model:
63-7580-30
brand:
STMicroelectronics
Product Description
Product Model: 63-7580-30Product Brand: STMicroelectron […]
Contact Us
Product Details
Product Model: 63-7580-30
Product Brand: STMicroelectronics
Features
- TRIAC, up to 6A, STMicroelectronics
Spec
- Quantity:1set(50pieces)
- Rated Average On-State Current : 4A
- Mounting Type : Through Hole
- Package Type : TO-220AB
- Maximum Gate Trigger Current : 5mA
- Repetitive Peak Reverse Voltage : 600V
- Surge Current Rating : 31A
- Pin Count : 3
- Maximum Gate Trigger Voltage : 1.3V
- Repetitive Peak Forward Blocking Voltage : 600V
- Maximum Holding Current : 10mA
- Dimensions : 10.4 x 4.6 x 9.15mm
- Length : 10.4mm
- Width : 4.6mm
- Height : 9.15mm
- Repetitive Peak Off-State Current : 0.005mA
- CODE No.:168-6239
