63-7561-25 Prysmian BW20S LSF M20 Cable Gland Kit, includes Earth Tag, Gland Body, Gland Nut, Lock Nuts, Shroud LSF20SBW
Product Description
Product Model: 63-7561-25Product Brand: Prysmian Featur […]
Contact Us
Product Details
Product Model: 63-7561-25
Product Brand: Prysmian
Features
- Armoured BW Indoor (SWA) LSF Gland Kit. The LSF type are suited to where the specification calls for the materials to be zero halogen, low smoke and fume rated. The LSF shroud complies with London Underground Ltd Engineering Standard E1042:A2 for fire safety performance. These types of glands provide clamping of the armour wires for electrical continuity and mechanical retention of the cable.
Spec
- Quantity:1bag(2pieces)
- Thread Size : M20
- Material : Steel
- Minimum Cable Diameter : 7mm
- Maximum Cable Diameter : 11.6mm
- Number of Cores : 1
- Number of Pieces : 2
- Series : BW20S LSF
- CODE No.:463-4225
