Spec

• Stirring capacity (mL): 300
• Size (mm): 60 x 60 x 60
• Speed: 300 ~ 1500 rpm
• Motor: DC brush motor (replaceable)
• Magnet: Neodymium Magnet (0.41 T)
• Top Material: SUS 304
• Load capacity: 1 kg
• Top dimensions: 50 x 60 mm
• Body weight: 0.5 kg
• Power supply: 100 ~ 240 VAC 50/60 Hz (AC adapter included)
• Recomm***ed rotor: phi 3 x 5 mm to Φ8 x 25 mm
• Example of body usable rotor
• phi 3 x 6 mm (1 -3252 - 03, 3 -6659 - 02)
• φ2×7mm(1-3252-04)
• φ3×8mm(1-3252-05)
• φ3×10mm(3-6659-01)
• φ4×6mm(7-218-01)
• phi 4 x 10 mm (1 -4206 - 01, 9 -870 - 01)
• φ5×15mm(1-4206-02)
• φ8×25mm(1-4206-04)
• *Body size excludes protrusions.
• *Suitable stirrer length and stirring capacity are approximate. It dep***s on the shape of the stirrer, solution, container shape, etc.
• *Stirrer not included.
• Inspection contents App***ix: Inspection inspection documents
• Actual speed, insulation resistance value and apPearance
• App***ix: Inspection Certificate documents
• *Products with Inspection Certificate are Azwan's original service that includes inspection of control and electric engine personnel and issuance of inspection documents at the time of shipment.
