63-7534-74 BALLUFF Inductive Sensor 5 mm Detection PNP-NO, 48mm Length, 10 → 30 V dc supply voltage BES 516-346-H2-Y
Product Description
Product Model: 63-7534-74Product Brand: BALLUFF Feature […]
Contact Us
Product Details
Product Model: 63-7534-74
Product Brand: BALLUFF
Features
- Inductive proximity switch, pin switch design. Sensors in die-cast aluminium housing Housing compatible with mechanical precision pin switches in accordance with DIN 43 693 Available with plug connector or cable gland
Spec
- Quantity:1piece
- Body Style : Block
- Output Type : PNP-NO
- Detection Range : 5 mm
- Terminal Type : M16 Gland
- Supply Voltage : 10 → 30 V dc
- Length : 48mm
- Width : 42mm
- Depth : 22mm
- Maximum DC Voltage : 30V
- Mounting Type : Flush Mount
- Switching Current : 130 mA
- Housing Material : Aluminium
- Short Circuit Overload Protection : Yes
- CODE No.:418-5060
