63-7523-44 Vishay VS-GBPC2512A, Bridge Rectifier, 25A 1200V, 4-Pin GBPC-A VS-GBPC2512A
Electronic/Electrical Parts and Controll Equipments

63-7523-44 Vishay VS-GBPC2512A, Bridge Rectifier, 25A 1200V, 4-Pin GBPC-A VS-GBPC2512A

model: 63-7523-44
brand: Vishay

Product Description

Product Model: 63-7523-44Product Brand: Vishay Features […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-7523-44
Product Brand: Vishay

Features

  • UL E54214. Bridge Rectifiers with Push-on Terminals, VS-GBPC25 Series, Vishay Semiconductor. Universal, 3-way terminals: Push-on, wrap around or solder High thermal conductivity package, electrically insulated case Center hole fixing Excellent power/volume ratio

Spec

  • Quantity:1box(100pieces)
  • Bridge Type : Single Phase
  • Peak Average Forward Current : 25A
  • Peak Reverse Repetitive Voltage : 1200V
  • Mounting Type : Screw Mount
  • Package Type : GBPC-A
  • Pin Count : 4
  • Diode Technology : Silicon Junction
  • Configuration : Single
  • Peak Non-Repetitive Forward Surge Current : 420A
  • Maximum Operating Temperature : +150 °C
  • Minimum Operating Temperature : -55 °C
  • Peak Forward Voltage : 1.1V
  • Peak Reverse Current : 5µA
  • Length : 28.6mm
  • Width : 28.6mm
  • CODE No.:169-5943
