Analyzer, Testing Equipment
2-5749-01 ［Discontinued］Gliding Microtome REM-710, SB REM-710/SB
model:
2-5749-01
category:
Analyzer, Testing Equipment
Product Description
Product Model: 2-5749-01 Features The REM-710/SB can pe […]
Contact Us
Product Details
Product Model: 2-5749-01
Features
- The REM-710/SB can perform "up/down movement of the sample base," "feed operation," "move to the home position," and "change the setting thickness" with one lever.
- By holding the knife at two points, it is equipped with a function to suppress the escape and vibration of the blade when slicing the hard tissue as standard to achieve a more beautiful slice.
- TU-213/DOBN is an oil surface gliding type microtome, which is suitable for slicing hard tissues without raising the sample stand when slicing.
- The oil tank mounted on the runway maintains smooth gliding performance.
- Cryosectioning is possible by combining electrofreezing.
- A dry ice cryocooler can be easily frozen by placing dry ice and alcohol into the recess of the cryocooler.
Spec
- Specification: Body large type gliding set
- Outer dimension (mm): 340 x 440 x 300
- Sliced pieces thickness adjustment: 2 type settings available capacity (rough-hewn, Real-hewn)
- Sample pedestal mechanism: Rotation mechanism, angle adjustment mechanism
- Sword brace: One touch set blade brace with vibration-proof bar
- Up or down dynamic feed: 40mm
- Thin sliced scale range: 0 - 5μm (0.25μm intervals), 5 - 10μm (0.5μm intervals), 10 - 20μm (1μm intervals), 20 - 30μm (2μm intervals), 30 - 50μm (5μm intervals), 50 - 120μm (10μm intervals),
- Power supply: AC100V±10% 50/60Hz 50W
- Usage environments: Temperature 10℃ - 40℃, Humidity 20% - 80%
- Weight: 32kg
- Accessories C-26, one touch set blade brace with S vibration-proof bar, OB-25 quick release clamp, Paraffin scrap tray, Vinyl cover
- Model number: REM-710・SB
- *Feather microtome holder set is sold separately.
