Analyzer, Testing Equipment
2-5087-01 ［Discontinued］Full Reflection Fluorescence X-Ray Analysis Device 200TX
model:
2-5087-01
category:
Analyzer, Testing Equipment
Product Description
Product Model: 2-5087-01 Features Equipped with SDD det […]
Contact Us
Product Details
Product Model: 2-5087-01
Features
- Equipped with SDD detector, it has high sensitivity comparable to ICP/atomic absorption equipment.
- The body weight of 8 kg is very light.
- You can analyze ppm to ppb levels.
- No need for liquid nitrogen or cooling water.
Spec
- Main unit size (mm): 340 x 175 x 214
- Body weight (kg): 8
- Measurement principle: Full reflection fluorescence X-ray analysis method
- Measurement target: Liquid, Drinking water, Soil seepage water, Sewage, etc.
- Measuring element: 13Al - 92U
- Slit mechanism: X-ray waveguide
- Sample pedestal: Quartz optical flat
- Sample chamber atmosphere: Atmospheric air
- X-ray rated output: 0 - 48kV, 0.2mA max/48 - 50kV, 0.175mA max
- Detector: Electronic cooling method Silicone drift detector
- Counting circuit: Digital processing method DSP
- Operating conditions: Temperature: 5 - 27℃, Humidity: 20 - 75% (non-condensing)
- Power supply: AC100V 5A (ground: D type ground)
- Option: Inkjet printer type color printer, PC, Carrying case, etc.
- Model number: 200TX
- *Regarding the introduction of products, it is necessary to notify the Labor Standards Supervision Office beforehand. *Please contact us for options. *Laptop is not included in the package.
