4-2072-01-22 Vacuum Cooling Plate with Pre-Shipment Inspection Document PRD-1
Product Description
Product Model: 4-2072-01-22Product Brand: AS ONE Corpor […]
Contact Us
Product Details
Product Model: 4-2072-01-22
Product Brand: AS ONE Corporation
Features
- Vacuum specification cooling and heating plate using Peltier element can be ***d for cooling and heating experiments under reduced pressure and vacuum drying.
- By creating a vacuum inside the transparent acrylic cover on the plate, it is possible to conduct experiments while checking the inside condition when the pressure is reduced.
- Comes with a snap lock for 4 pieces, allowing gas replacement after decompression.
- Easy to observe low temperature vacuum dryer!
Spec
- Top Plate Size (mm): 150 x 150
- Temperature Zone (°C): 0~60
- Material: Body/Steel, Cover/Acrylic
- External Dimensions: Body/170 x 170 x 170 mm, Control Box/150 x 195 x 95 mm
- Allowable Vacuum Degree: -0.09 MPa
- Outer Diameter: One Touch Valve for Φ6 Tube x 2
- Power: 100 VAC 50/60Hz
- Weight: Body/2.5 kg, Control Box/2.5 kg
- Power consumption: approx. 100 W
