Spec

• Output Voltage: 0 to 10 V
• Output Current: 0 to 20 A
• INPUT
• Voltage/Frequency: 85 to 265 VAC continuous input (Single Phase 47 to 63 Hz)
• Inrush Current: 200 W: 100/200 VAC 15/30 A or Less, 400 W: 25 A or Less, 600 W: 30 A or Less, 800 W: 30 A or Less
• CV Mode
• Maximum load variation: rated voltage 0.01% + 2 mV no-load - constant input voltage at full load. Measured the voltage at the remote sensing point.
• CC mode
• Maximum load fluctuation: When the rating output current is 0.01% + 5mA and the output voltage is variable (Inside rated voltage), this is the constant input voltage.
• interface
• Analog control: Output voltage and current control by external voltage (0 - 5/0 -10 V) or external resistance (0 - 5/0 -10 Ω). Monitor terminal and interlock function are available.
• Digital control: (serial communication) RS 232 C, RS 485, USB port standard mounting, LAN and GPIB support as options.
• Serial/Parallel Operation Unit: 2, Parallel Connection: 6 (Same model for both chisel)
• Protection Function: OVP (overvoltage protection), UVL (Lower limit of output voltage), UVP (Output voltage drop protection), Heat Protection, Foldback Function (Shut off when operating mode is switched between CV and CC)
• Accessories: Instruction Manual (English version with CD-ROM), Output Terminal Cover, Analog Programming Connector, RS 485 Serial Link Cable, AC Cable (125 V/15 A, L = 2 m, JIS C 8303 Type)
• Size: 70 x 350 x 83 mm
