3-9512-02 Economy Tubular Electric Furnace with Program Function (16 Steps 4 Patterns) ROM-500P
Product Description
Product Model: 3-9512-02Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-9512-02
Product Brand: AS ONE Corporation
Features
- You can set the temperature and check the furnace temperature on the digital display.
- You can set up to 4 patterns of 16 step programs.
- Speedy warming: High performance type with a quick temperature rise time of about 28 minutes to the maximum temperature.
- Heating in an inert environment is possible: A gas displacement unit allows heating while replacing with an inert gas.
- The material of the core tube can be selected according to the application.
- Easy-to-*** compact and personal tubular electric furnace
Spec
- External dimensions (mm): 210 x 210 x 295
- Inner furnace dimensions (mm): phi 50 x 140
- Temperature setting range: 100 ~ 900 degrees Celsius/Normal temperature: 800 degrees Celsius
- Temperature setting resolution: 1 degree C
- Timing resolution: 1 minute
- Function: Program function (16 steps, 4 patterns)
- Temperature control method: PID control
- Safety mechanism: Sensor fault detection, excessive rise prevention relay, overcurrent f***
- Sensor: K thermocouple
- Heater capacity: 800 W
- Materials: Exterior/Steel Heat resistant coating, Furnace/Ceramic fiber, Ceramic core tube/PT1 material (alumina 60%), Alumina 99% core tube/PT0 material (alumina 99.6%)
- Power supply: 100 VAC 50/60 Hz
- Weight: approximately 5.2 kg
- *The main unit does not come with a core tube. Be sure to *** the core tube when using it.
