Electronic/Electrical Parts and Controll Equipments
63-7470-24 EPCOS Standard Series Metal Oxide Varistor 760pF 100A, Clamping 595V, Varistor 360V B72220S0231K101
Product Description
Product Model: 63-7470-24Product Brand: EPCOS Features […]
Contact Us
Product Details
Product Model: 63-7470-24
Product Brand: EPCOS
Features
- UL, CSA, VDE. Metal Oxide Varistors Standard Series. Standard radial epoxy-coated MOV with tinned-copper leads. Tinned copper wire leads with a ceramic body coated with epoxy resin Rated for surge current (8//20 μs) and for energy (2ms)
Spec
- Quantity:1bag(5pieces)
- Varistor Voltage : 360V
- Maximum AC Voltage Rating : 230V
- Maximum DC Voltage Rating : 300V
- Clamping Voltage : 595V
- Clamping Current : 100A
- Energy : 130J
- Series : Standard
- Diameter : 21.5mm
- Maximum Surge Current : 8000A
- Capacitance : 760pF
- Thickness : 5.1mm
- Dimensions : 21.5 (Dia.) x 5.1mm
- Lead Pitch : 10mm
- CODE No.:289-7294
