Spec

• [<2 axis stage controller> Common specification]
• Major function controller function: ○
• Major function number of control axes: 2 axes
• Major function internal program control: -
• Major function feedback control: -
• Major function circular interpolation control: -
• Major function straight line interpolation control: -
• Major function driver function: Standard
• Major function microstep (maximum division counts): 2 division
• Major function drive current: 0.17 - 0.85A/phase
• General specification power voltage: AC100V 50/60Hz
• General specification power consumption: 50VA
• General specification operation temperature: 5 - 40℃
• General specification storage temperature: -
• General specification ambient humidity: 20 - 80％RH
• General specification outer dimensions (W x H x D): 200 x 52 x 172mm
• General specification weight: 2kg
• Interface GP-IB: ○
• Interface RS232C: ○
• Interface USB: -
• Interface ethernet: -
• Performance specification coordinate display range: ±9,999,999
• Performance specification maximum setting movement amount: 16,777,214pulse
• Performance specification maximum drive speed: 20,000pps
• Performance specification minimum drive speed: 100pps
• Performance specification acceleration/deceleration time: 0 - 1,000ms
• I/O specification origin sensor: -
• I/O specification proximity sensor: -
• I/O specification CW (+) limit: ○
• I/O specification CCW (?) limit: ○
• I/O specification general-purpose input: 4 points
• I/O specification general-purpose output: 4 points
• I/O specification control input: 3 points
• I/O Specification control output: -
• I/O Specification trigger Output: -
• Control command return to mechanical origin: ○
• Control command logical origin setting: ○
• Control command relative position drive: ○
• Control command absolute position drive: ○
• Control command jog operation: ○
• Control command position specifications: -
• Control command circular interpolation control: -
• Control command straight line interpolation control: -
• Control command drive: ○
• Control command decelerating stop: ○
• Control command emergency stop: ○
• Control command speed settings: ○
• Control command motor free/hold: ○
• Control command port input: -
• Control command port output: -
• [Individual specification]
• Product name: 2 axis stage controller
