61-6983-26 ［Discontinued］Thin Type Long Stroke Stage 80 x 80mm KLSA-100X
Product Description
Product Model: 61-6983-26Product Brand: SIGMAKOKI CO., […]
Contact Us
Product Details
Product Model: 61-6983-26
Product Brand: SIGMAKOKI CO., LTD.
Features
- It is thin and can be moved for a long time.
- A thin automatic stage that can be ***d in combination to minimize stage height.
- Four linear guide blocks have been optimally placed to improve the accuracy of repeated positioning.
- We recomm*** the KLSA with an aluminum body for price and the KLSS with an iron body for rigidity.
Spec
-
[
Common specification] - Motor type: 5 phase stepping motor 0.75A/phase (Oriental Motor (Co., Ltd.))
- Motor product number: PK545-NBW (□42mm)
- Motor step angle: 0.72°
- Sensor power voltage: DC5 - 24V±10%
- Sensor power consumption: 45mA or less (15mA per 1 sensor)
- Sensor control output: NPN open collector output 50mA
- Sensor output logic: When shading: Output transistor OFF (non-conducting): Limit sensor, When shading: Output transistor ON (conducting): Origin sensor
- Compatible driver: SG-5M, SG-55M, SG-514MSC, MC-7514PCL
- Compatible controller: SHOT-302GS, SHOT-304GS, HIT-M・HIT-S, PGC-04
- [Individual specification]
- Movement amount: 100mm
- Table surface size: 80 x 80mm
- Feed crew: Ball screw diameter φ8mm, Lead 2mm
- Movement guide: Linear guide
- Stage top side material: Aluminum
- Surface treatment: Black anodic oxide
- Mass: 2.2kg
- Resolution (full): 4μm/Pulse
- Resolution (half): 2μm/Pulse
- Max speed: 30mm/sec
- Positioning accuracy: 15μm
- Repeatable positioning accuracy: ±1μm
- Withstand load: 147N (13.0kgf)
- Moment rigidity/pitch: 0.05″/N・cm
- Moment rigidity/yaw: 0.05″/N・cm
- Moment rigidity/roll: 0.1″/N・cm
- Lost motion: 4μm
- Backlash: 1μm
- Parallelism: 50μm
- Running parallelism: 10μm
- Pitching: 20″
- Yawing: 15″
- Sensor product number: Microphoto sensor: PM-L24 (SUNX (Co., Ltd): Limit, Origin sensor
- Limit sensors: Is available
- Origin sensor: Is available
- Proximity origin sensor: No
- RoHS conform product
