Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature points: 9 37 degrees C, CO2 concentration
• Capacity (L): 50
• External dimensions (mm): 490 x 460 x 680
• Temperature setting range: room temperature + 5 ~ 50 degrees C
• Temperature Sensor: Platinum temperature resistor
• CO2 concentration range: 0 ~ 20%
• CO2 sensor: NDIR (infrared) type
• Heating method: Direct heat
• Humidification system: Natural evaporation system (attached tray water injection)
• Convection: Internal circulation fan
• Safety device: overcurrent protective f***/overtemperature protection device (digital setting)
• Internal dimensions: 350 x 325 x 440 mm
• Number of shelves: 3
• Shelf board dimensions: 330 x 310 mm
• Shelf position: 8 levels (30 mm pitch)
• Operation panel: Touch panel (analog resistive film type)
• Power supply: 100 VAC 50/60 Hz Cord length/1.9 m
• Security settings: 4-digit PIN code lock with emergency physical key
• *Use only for research and experimental purposes. It can not be ***d for medical purposes.
• Local validation services (IQ/OQ) are also available.　Please contact us.
• *The on-site validation service is a service that performs installation qualification (IQ) and operational performance qualification (OQ) at the installation site and submits an inspection form.
• *If you would like to request a local IQOQ, please contact us separately. We will need your installation address for the estimate.
