61-9941-17 Fluorocarbon Resin Diaphragm Valve (Manual Type) PTFE SMP2-8TF-BA
Product Description
Product Model: 61-9941-17Product Brand: Flon Chemical F […]
Contact Us
Product Details
Product Model: 61-9941-17
Product Brand: Flon Chemical
Features
- Turn the back pressure resistant "manual valve" handle to the right to stop the fluid and to the left to allow the fluid to flow.
- After adjusting the handle, secure it with a lock nut.
- "Indep***ent seal system" ... Absorbs the effect of heat cycle.
- Waveform diaphragm ... Realizes high durability.
- "Flat Seal" ... Seal structure with low dust emission.
- "Panel mounting nut" and "Base plate" ... Standard equipment.
- "Connection Method" ... FIT-ONE joint.
Spec
- Adaptive tube (φ): 6 x 4
- Orifice (φ): 7
- Fluid ***d: Chemicals, Pure water
- Liquid temperature: 10 - 100℃
- Atmosphere temperature: 0 - 40℃
- Liquid junction material Diaphragm PTFE, Body PTFE
- Fluid pressure: IN->OUT0 - 0.5MPa
- Back pressure: 0 - 0.5MPa
