63-7438-95 Alps Electric Rotary Carbon Potentiometer with a 6 mm Dia. Shaft, 50kΩ, ±20%, 0.05W, Logarithmic RK27112MC01P RK27112MC01P
Product Description
Product Model: 63-7438-95Product Brand: Alps Alpine Fea […]
Contact Us
Product Details
Product Model: 63-7438-95
Product Brand: Alps Alpine
Features
- Models RK1681□ / MG0 and RK2711□MC0 are Motor driven. 27mm Dual Potentiometers. Brought to you by Alps, RK27 Series of dual potentiometers are a high quality with a rugged construction and smooth operation. The RK27 Series potentiometer is particularly suitable for professional hi-fi equipment. Features and Benefits:. PCB or panel mountable End slotted metal shaft Metal mounting nut and washer supplied Motor voltage: 4 → 6Vdc Motor current at *** slip: 150mA at 4.5Vdc Gang error -60dB → 0dB : 2dB max. Rotational life of 15000 Cycles Mounting bush M9 L7
Spec
- Quantity:1piece
- Potentiometer Type : Rotary
- Maximum Resistance : 50kΩ
- Number of Turns : 1
- Power Rating : 0.05W
- Electrical Taper : Logarithmic
- Element Material : Carbon
- Mounting Type : Panel Mount, Through Hole
- Termination Style : Pin
- Shaft Length : 20mm
- Shaft Diameter : 6 mm
- Tolerance : ±20%
- Series : RK27
- CODE No.:234-6617
