Spec

• Outer dimensions (mm): 595 x 340 x 570
• Inner dimensions (mm): 50 x 700
• Inner capacity (L): 1.2
• Control method: PID program control (No autotuning)
• Control R class thermocouple x 4 pieces (Temperature control x 3 pieces, overheating prevention x 1 piece)
• Maximum temperature: Normal/1200 °C, set/1250 °C
• Function: Program setting (16 steps and 6 patterns), timer
• Heater: 88 V 800 W x 3 circuits
• Power supply: Single-phase 200V 50/60Hz 7.2 kW 36 A
• Power cord length: about 3 m (With rounded terminal at the ***)
• Safety device: Indep***ent overheating prevention (set temperature digital input), door switch, overcurrent breaker, self-diagnosis function (The main relay is turned off when the sensor or heater is disconnected.)
• Material: Exterior/steel heat-resistant paint, heater bobbin/ceramic, handle/wood
• Tubular furnace diameter: φ50mm
• *The core tube is not attached.
